United KingdomThe Micromax Xtreme II 12-LED Dash Light is supplied complete with cigar plug connector, flashback shield, adjustable mounting bracket, suction cups for windscreen mounting and adhesive Velcro pads for dash mounting.
Micromax Xtreme II 12-LED Dash Light
The 12-LED Dash Light Micromax Xtreme II incorporates twin super-bright 6-way LED modules with laser cut optic technology for an extra wide viewing angle.
More product information
About the product
Benefits
- A total of 12 x hi intensity 1 watt LEDs
- 1.2 amps maximum output (12v)
- 26 built-in, selectable flash patterns
- Reverse polarity protection
- Available in blue or amber
- Max power 14.4 watts
- 12v operation only
Drawings
Downloads
Technical Data
- Nominal Voltage
- 12 VDC
- LED Colour
- Amber, Blue
- Lens Colour
- Clear
- Number of LEDs / LED Modules
- 12
- Flash Patterns
- 26 Built-in
- Mounting
- Suction cup Adhesive Velcro Pads
- Housing Colour
- Black
- Dimensions
- w236mm x h45mm x d150mm
- Approvals
- EMC ECE-R10
| Flash Patterns | |||
|---|---|---|---|
| 1 | Kit Scan | 14 | Single H/L (split) |
| 2 | Outside-In Single | 15 | Single (all) |
| 3 | Outside-In Ultra | 16 | Double (all) |
| 4 | Side-by-Side Single | 17 | Quad (all) |
| 5 | Side-by-Side Ultra | 18 | Quint (all) |
| 6 | Random (default) | 19 | Mega (all) |
| 7 | Single (split) | 20 | Ultra (all) |
| 8 | Double (split) | 21 | Single-Quad (all) |
| 9 | Quad (split) | 22 | Single H/L (all) |
| 10 | Quint (split) | 23 | Steady 2 (California) |
| 11 | Mega (split) | 24 | Steady 4 (all) |
| 12 | Ultra (split) | 25 | Left Chaser |
| 13 | Single-Quad (split) | 26 | Right Chaser |
